Knipex 77 02 115 | Electronics Diagonal Cutter With Box Joint | Multi-Component Handle | Mirror Polished – 115mm
35.00 JD
77 02 115 Electronics Diagonal Cutter
With box joint
– Durable, load-optimised design with backlash-free box joint
– High, slim sleeves for fine and comfortable gripping between thumb and index finger
– Less physical effort due to very high transmission ratio
– Load-optimised for a more direct feel when working
– Low-friction double spring for smooth and even opening
– The mirror polish in combination with a fine oil film provides rust protection – no circuit faults caused by peeling chrome from plated tools
– Cutters additionally laser hardened, cutter hardness at least 62 HRC
– Round head, with small bevel
Technical attributes :
– Cutting capacities medium hard wire (diameter) – Ø 1.2 mm
– Cutting capacities hard wire (diameter) – Ø 0.6 mm
– Cutting capacities soft wire (diameter) – Ø 01 mm
– Jaw length (B) – 14 mm
– Jaw thickness (joint) (D) – 7.5 mm
– Head width (A) – 11 mm
| Weight | 0.70 kg |
|---|
