Knipex 68 01 180 | End Cutter | Coated Handle | Black Atramentized – 180mm
14.00 JD
The Knipex 68 Series End Cutter is one of the most popular products in our range, and for good reason!
Key Features:
– The head shape provides optimal movement when tightening steel mesh knots during reinforced concrete work.
– Cutting edges for soft and hard wire.
– Suitable for twisting and cutting binding wire.
– Cutting edges are additionally hardened, to a hardness of 61HRC.
– High-grade special tool steel, forged, and multi-stage oil hardened.
Product Specification:
– Pliers: Black Atramentized
– Head: Polished
– Handles: Plastic Coated
Technical Attributes :
– Cutting capacities medium hard wire (diameter) – Ø 3.2 mm
– Cutting capacities hard wire (diameter) – Ø 2.5 mm
– Cutting edge length mm (C) – 29 mm
| Weight | 0.284 kg |
|---|
